MBS.003014Student Microscope
  • /usr/575/images/Products/Y/57517727.jpg
  •
  •
  •

With light and handy structure, 360° rotatable head and comfortable operation, it is an ideal educational instrument.

Specification
MBS.003014-A1
MBS.003014-A2
MBS.003014-A3
Head
Monocular head, inclined 45°
Eyepiece
Wide Field Eyepiece WF10x/18
Objective
Achromatic objective 4x
Achromatic objective 4x
Achromatic objective 4x
Achromatic objective 10x
Achromatic objective 10x
Achromatic objective 10x
Achromatic objective 40x
Achromatic objective 40x
Achromatic objective 40x

Achromatic objective 100x
Nosepiece
Triple nosepiece
Triple nosepiece
Quadruple nosepiece
Focusing
Coarse Focusing
Separate Coarse&Fine Focusing
Separate Coarse&Fine Focusing
Stage
Plain Stage with Slide Clips 120x130mm
Plain Stage with Slide Clips 120x130mm
Attachable Mechanical Stage 120x130mm/ 60x30mm
Focusing
Separate coaxial knobs for coarse & fine adjustment

Condenser

Single Lens with Iris
Single Lens with Iris
Abbe N.A.1.25 with Iris,
Spiral up & down
Illumination
Plan-concave Mirror
Built-in Illumination, Incandescent Lamp 110V/ 220V/ 15W
Built-in Illumination, Incandescent Lamp 110V/ 220V/ 15W




Item
Optional Accessories
Eyepiece
Wide Field Eyepiece P16x
