MBS.003016Student Microscope
  • /usr/575/images/Products/Y/57517729.jpg
  •
  •
  •

With sharp image and reasonable unit price, it is an ideal instrument for student use.

Specification
MBS.003016
Head
Verticle monocular head
Eyepiece
Huygens Eyepiece H5x、H10x
Huygens Eyepiece H16x
Objective
Achromatic objective 10x
Achromatic objective 40x
Achromatic objective 100x
Nosepiece  Triple nosepiece
Stage
Attachable mechanical stage 110×120mm/ 60×30mm
Condenser
Abbe N.A.1.25 with Iris diaphragm and filter
Focusing
Coaxial Coarse & Fine Focus Adjustment System, Range 24mm, Fine Division 2μm
Filter
Blue filter
Green filter
Illumination
Plan-concave mirror



Item
Optional Accessories
Objective Achromatic objective 4x
Achromatic objective 60x
Illumination System
 Attachable Illuminator
