MBE.040001Binocular/Trinocular Elementary Microscope, 40X~1000X
  • /usr/575/images/Products/Y/57518467.jpg
  • /usr/575/Picture/Y/11443.jpg
  •
  •

MBE.040001 biological microscope is designed for teaching, clinical verify. The microscope with original style, steady structure, convenient operation and clear image is suitable for observing various biological specimens, and mostly applied in school, college, hospital and family.

Specification
MBE.040001-B
MBE.040001-T
Head
 Compensation Free Binocular, 30°inclined,55mm-75mm Compensation FreeTrinocular,30°inclined,55mm-75mm
Eyepiece
 WF10X /18mm
Objective
Achromatic 4X
Achromatic 10X
Achromatic 40X, Spring
Achromatic 100X, Spring
Nosepiece
 Quadruple Revolving Nosepiece
Focusing
 Coaxial Coarse and Fine Focusing Scale Value 0.002mm
Stage
Double Layer Mechanical Stage,Size135mmx135mm,Moving Range70mmx30mm
Condenser
 ABBE N.A.1.25Condenser with Iris Diaphragm & Filter
Illumination
 Halogen Bulb 6V/20W,AC 220V/110V,Brightness Adjustable

Item
MBE.040001 Optional Accessories
Head Compensation Free Binocular,48mm-75mm
Compensation FreeTrinocular,48mm-75mm
Demonstration Head
Eyepiece
 Wide Field Eyepiece WF16x
Wide Field Eyepiece WF20x
Objective

 Achromatic objective 20x
Achromatic objective 60x
Illumination Reflective Mirror
LED
