MBE.004009Binocular/Trinocular Elementary Microscope, 40X~1000X

MBE.004009 biological microscope is designed for teaching, clinical verify. The microscope with original style, steady structure, convenient operation and clear image is suitable for observing various biological specimens, and mostly applied in school, college, hospital and family.

Specification	MBE.004009-B	MBE.004009-T
Head	Binocular Head, Inclinded 30°, Rotatable 360° Interpupillary Distance 50-75mm, Diopter Adjustable ±5	Tinocular Head, Inclinded 30°, Rotatable 360° Interpupillary Distance 50-75mm, Diopter Adjustable ±5
Eyepiece	Wide field eyepiece WF10x/ 18
Objective	Achromatic Objective 4x / 0.1
	Achromatic Objective 10x / 0.25
	Achromatic Objective 40x / 0.65(S)
	Achromatic Objective 100x / 1.25(O,S)
Nosepiece	Quadruple Nosepiece
Focusing	Coaxial Coarse And Fine Focusing Knob, Coarse Stroke 22mm, Fine Division 2μm, Condenser Up-down Range 25mm
Stage	Double Layer Mechanical, Size 120X115mm, Moving Range 76 x50mm
Condenser	Abbe N.A.1.25 With Aperture Iris Diaphragm, Aperture Center Is Adjustable
Filter	Built-in Blue Filter Φ38.5mm
Illumination	6V 20W Halogen Lamp With Brightness Control(100V-240V)
Packing	1pc/carton, Size 34x24x42cm, G/N Weight 6.5/5.5 Kgs

Item	Optional Accessories
Head	Monocular Head, Inclinded 30°, Rotatable 360°
Eyepiece	WF5x/20mm
	WF16x/13mm
	WF10x/18mm With Pointer
	WF10x/18mm With Micrometer 0.1mm/Div
	WF16x/13mm With Micrometer 0.1mm/Div
Objective	Achromatic objective 20x
	Achromatic objective 60x(S)
	Plan Achromatic Objective 20x
	Plan Achromatic Objective 60x (S)
Adapter	CCD Adapter 0.5x （Focus Adjustable）
Adapter	CCD Adapter 1.0x （Focus Adjustable）
Polarization Set	Analyzer & Polarizer
Dark Field Condensor	Dark Field Ring Fo 4x- 40x Objective
Illumination	Plano-concave mirror Φ52mm
	Upgrade to 0.3W LED, Rechargable
	Upgrade to 3W LED, Non-rechargable
