MBE.017020Monocular/Binocular Elementary Microscope, 40X~400X
  • /usr/575/images/Products/Y/57519078.jpg
  • /usr/575/Picture/Y/11559.jpg
  •
  •
  • Total Magnification 40X~400X
  • LED, DC 5V Power Supply
Specification
MBE.017020-M
MBE.017020-B
Head

Monocular,45° inclined,360° Rotatable

Compensation Free Binocular,45° inclined,360° Rotatable
Eyepiece
WF10X
Objective
195 Achromatic Objective 4x
195 Achromatic Objective 10x
195 Achromatic Objective 40x
Nosepiece
Tripe Nosepiece, Backward
Focusing
Coarse Focus Adjustment,Coarse Range:15mm
Stage
Plain Stage with Clips,Size:90mmx90mm
Condenser
ABBE N.A.0.65 Condenser with Disc Diaphragm
Illumination
LED, DC 5V Power Supply
