Sliding Trinocular Head, 45° Inclined, With Photo Adapter
|
|
Eyepiece
|
Wide Field WF10x/18mm
|
|
Wide Field WF16x/11mm
|
|
|
Achromatic objective 4x
|
|
Achromatic objective 10x
|
|
Achromatic objective 40x
|
|
Achromatic objective 100x
|
|
|
|
|
|
Double Layer Mechanical Stage, 140*140mm, Mvoing Range 50*75mm
|
|
Condenser
|
N.A.1.25 Abbe Condenser, Iris Diaphargm, With Filter Holder
|
|
Focusing
|
Low Position Coaxial Coarse & Fine Focusing. Fine Focusing Scale 0.002mm, With Tension Adjustment, With Up Limit
|
|
Filter
|
Blue filter
|
|
Yellow filter
|
|
Green filter
|
|
|
Built-in Illumination 6V20W Halogen Lamp
|
|
Plan-concave Mirror
|
|
|
|
|
|
|
Dark Field Condenser, N.A. 0.7~0.9, Dry
|
|
Dark Field Condenser, N.A. 1.25~1.35, Immersion
|
| Dark Field Objective, Achromatic 100x, With Cone Diaphragm |
| Dark Field Objective, Plan Achr. 100x, With Iris Diaphragm |
|
