Binocular/Trinocular Compound Microscope, 40X~1000X_IHPVISION:Microscope,Digital Vision

MBL.003031Binocular/Trinocular Compound Microscope, 40X~1000X

Excellent image quality with infinitive optical system.
Comfortable operating with ergonomic structure.
Better illumination with sliding-in centerable condenser, Convenient replacement with phase contrast and dark field condenser.

Specification	MBL.003031-24	MBL.003031-34
Head	Seidentopf Binocular Head, Inclined at 30°, Interpupillary Distance 52-75mm,Eyepiece Tubes Rotated 180° Up & Down	Seidentopf Trinocular Head, Inclined at 30°, Interpupillary Distance 52-75mm,Eyepiece Tubes Rotated 180° Up & Down
Eyepiece	Wide Field Eyepiece WF10x/18mm
Magnification	40x~1000x
Objective	Infinite Semi-Plan Achromatic Objective 4x
	Infinite Semi-Plan Achromatic Objective 10x
	Infinite Semi-Plan Achromatic Objective 40x
Nosepiece	Backward Quadruple Nosepiece
Stage	Double Layer Mechanical Stage, Size 140×140mm, Moving Range 75×50mm
Condenser	Sliding-in Center Adjustable Condenser N.A.1.25
Focusing	Coaxial Coarse & Fine Adjustment, Moving Range 20mm
Illumination	S-LED Illumination, Adjustable Brightness

Item	Optional Accessories
Eyepiece	WF10x/20mm, Diopter Adjustable
Objective	Infinity Plan Achromatic Objective 4x
	Infinity Plan Achromatic Objective 10x
	Infinity Plan Achromatic Objective 40x
	Infinity Plan Achromatic Objective 100x
Illumination	6V20W Halogen Lamp, Brightness Adjustable
LED EPI-Fluorescent Kit	EPI Light 3W LED 465~475nm, B Excite Filter BP460~490
LED EPI-Fluorescent Kit	EPI Light 3W LED 525~530nm, G Excite Filter BP510~550
Phase Contrast Attachment	Infinity Plan Turret Phase Contrast Set --Infinity Plan Turret Phase Contrast Condenser --Ininity Plan Phase Contrast Objective 4x,10x,40x,100x --Centering Telescope 10x
Phase Contrast Attachment	Infinity Achromatic Turret Phase Contrast Set --Infinity Achromatic Turret Phase Contrast Condenser --IninityAchromatic Phase Contrast Objective 4x,10x,40x,100x --Centering Telescope 10x
Dark Field Attachment	Dark Field Condenser, Dry, N.A.0.7~0.9
	Dark Field Condenser,Immersion, N.A.1.25~1.36
	Dark Field Objective, Infinity Plan 100X, For Immersion Dark Field Observation
	Dark Field Objective, Infinity Plan 100X, With Iris Diaphragm For Immersion Dark Field Observation
