MBL.003032-34
|
|
|
Siedentopf binocular head, inclined at 30°, interpupilary distance 48-75mm
|
Siedentopf trinocular head, inclined at 30°, interpupilary Distance 55-75mm
|
|
Eyepiece
|
Wide field eyepiece WF10x/ 18
|
|
|
Achromatic objective 4x
|
|
Achromatic Objective 10x
|
|
Achromatic Objective 40x
|
|
Achromatic Objective 100x
|
|
|
Backward quadruple nosepiece
|
|
Focusing
|
Coaxial coarse & fine knob, moving range 24mm, fine division 0.004mm
|
|
|
Double layers mechanical stage132x142mm/ 75x40mm
|
|
Condenser
|
Abbe condenser N.A.1.25 with Iris diaphram & filter
|
|
Illumination
|
LED 3W, brightness adjustable
|
