MBL.003035Binocular/Trinocular Compound Microscope, 40X~1000X
  • /usr/575/images/Products/Y/57517711.jpg
  •
  •
  •

With excellent optical system and reliable structure, it makes the image much sharper, and the operation easier. With wide range of accessories [e.g. dark field, phase contrast, epi-fluorescent] and advances to expand the application scope of the N-200M, the versatility of the microscope provides More Microscopy for you.

Specification
MBL.003035-24
MBL.003035-34
Head
Siedentopf binocular head, inclined at 30°,
Siedentopf trinocular head, inclined at 30°
Eyepiece
Wide field eyepiece WF10x/ 18
Objective
Semi-plan Achromatic Objective 4x
Semi-plan Achromatic Objective 10x
Semi-plan Achromatic Objective 40x
Semi-plan Achromatic Objective 100x
Nosepiece
Backward quadruple nosepiece
Stage
Double Layers Mechanical Stage 140x140mm/ 75x50mm
Condenser
Abbe condenser N.A.1.25 with Iris diaphram & filter
Filter
Blue Filter
Green Filter
Illumination
Halogen lamp 6V/ 20W, brightness adjustable

Item
Optional Accessories
Eyepiece
Wide Field Eyepiece WF16x/ 11
Objective
Plan achromatic objective 4x
Plan achromatic objective 10x
Plan achromatic objective 20x
Plan achromatic objective 40x
Plan achromatic objective 60x
Plan achromatic objective 100x
Nosepiece
Quintuple nosepiece
Phase Contrast Attachment
Simple phase contrast set
Sliding phase contrast set
Turret phase contrast set
Polarization Set
Simple polarization set
Dark Field Condensor
Dark field condenser (Dry) N.A. 0.9
Dark field condenser (Oil) N.A. 1.25-1.36
Illumination
Kohler illumination
