MBL.040012Binocular/Trinocular/Monocular Compound Microscope, 40X~1000X
  • /usr/575/images/Products/Y/57519499.jpg
  • /usr/575/Picture/Y/11585.jpg
  • /usr/575/Picture/Y/11586.jpg
  •

The series microscope is widely used in Biology. Histology, Pathology, Medicament, chemistry research and Clinical examination. It can also be used for education in Colleges and Schools.

Major differences between each models

  • MBL.040012-B:    Binocular
  • MBL.040012-T:    Trinocular
  • MBL.040012-M:   Monocular



Specification
MBL.040012-B
MBL.040012-T
MBL.040012-M
Head
 Compensation Free Binocular Head .Inclined at 30° Compensation Free Trinocular Head at 30° Monocular Head.Inclined at 45°
Eyepiece
WF10x
Objective
Achromatic Objective 4x
Achromatic Objective 10x
Achromatic Objective 40x, SPring
Achromatic Objective 100x, Spring, Oil
Nosepiece
Quaruple Revolving Nosepiece
Focusing
Coaxial Coarse & Fine Focusing Knobs. Fine focusing scale 0.002mm
Stage
Double layer Mechanical Stage:125mmx130mm,Moving Range:75mm × 50mm
Condenser
Abbe Condenser N.A.=1.25, with Iris Diaphragm and Filter
Collector
High brightness light collector
Illumination High point fixed illuminate or Kohler illumination,
Halogen tungsten bulb AC 85V-230V 12V/20W Adjustable Brightness

Item
Optional Accessories
Eyepiece
 WF16X
WF20X
WF25X
P16X
Objective

 Achromatic objective 20x
Achromatic objective 60x, Spring
Semi-Plan Achromatic Objective 4x
Semi-Plan Achromatic Objective 10x
Semi-Plan Achromatic Objective 20x
Semi-Plan Achromatic Objective 40x (S)
Semi-Plan Achromatic Objective 60x (S)
Semi-Plan Achromatic Objective 100x (S)
CCD Adapter
0.5x
0.57x
0.75x
