MBL.017028Finity,Binocular/Trinocular/Monocular Compound Microscope, 40X~1000X
  • /usr/575/images/Products/Y/57523384.jpg
  • /usr/575/Picture/Y/11660.jpg
  • /usr/575/Picture/Y/11661.jpg
  •
  • Finity optical system
  • Finite 195 Series Achromatic Objectives
  • It is an entry-level microscope and is especially appreciated when budget is limited. The basic model comes with a fixed lens condenser and a plain stage.All models with an integrated mechanical stage are supplied with an Abbe condenser.
Specification
MBL.017028-M
MBL.017028-B
MBL.017028-T
Head
Monocular Viewing Head, Inclined at 30º ,360ºRotatable
Seidentopf Binocular Viewing Head, Inclined at 30º ,360ºRotatable Seidentopf Trinocular Head,Inclined at 30º ,360ºRotatable
Optical System Finity Optical System
Eyepiece
Wide field eyepiece WF10x/ 18
Objective
Achromatic Objective 4x
Achromatic Objective 10x
Achromatic Objective 40x
Achromatic Objective 100x s(Oil)
Nosepiece
Backward quadruple nosepiece
Focusing
Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke36mm
Stage
Double Layer Mechanical Stage 142x132mm , Moving Range75mmx50mm
Condenser
Abbe Condenser N.A.1.25 with Diaphragm, Filter
Illumination
Halogen lamp 6V/ 20W, brightness adjustable

Item
Optional Accessories
Pointer Eyepiece
Wide Field Eyepiece WF10X/18mm
Eyepiece Wide Field Eyepiece WF16X/13mm
Wide Field Eyepiece WF20X/11mm
Objective

Achromatic objective 20x
Achromatic objective 60x
Plan Achromatic Objective 4x
Plan Achromatic Objective 10x
Plan Achromatic Objective 40x
Plan Achromatic Objective 100x s(Oil)
Nosepiece
Backward quintuple nosepiece
CCD Adapter
1X
Illumination
3W LED Brightness Adjustable, Rechargeable, Without Batteries
