MBL.003093Infinity,Binocular/Trinocular Compound Microscope, 40X~1000X
  • /usr/575/images/Products/Y/57525150.jpg
  • /usr/575/Picture/Y/11665.jpg
  • /usr/575/Picture/Y/11666.jpg
  •

 Advanced biological Microscope for educational, teaching, life science and clinical applications.

  • Wide Field Eyepiece WF10x/ 20
  • Infinite Semi Plan Achromatic Objective
  • Backward quadruple nosepiece
Specification
MBL.003093-B
MBL.003093-T
Head
Seidentopf binocular head, inclined at 30°,360° Rotatable,interpupilary 47-75mm
Seidentopf trinocular head, inclined at 30°,interpupilary 47-75mm
Eyepiece
Wide Field Eyepiece WF10x/ 20
Objective
Infinite Semi Plan Achromatic Objective 4x
Infinite Semi Plan Achromatic Objective 10x
Infinite Semi Plan Achromatic Objective 40x
Infinite Semi Plan Achromatic Objective 100x(S)(Oil)
Nosepiece
Backward quadruple nosepiece
Focusing
Coaxial coarse & fine adjustment system, range 24mm, fine division 0.002mm
Stage
Double layer mechanical specimen stage. 216 x 150 mm Travel area 78 x 54 mm, Right hand stage handle
Condenser
Abbe condenser N.A.1.25 with Iris diaphram
Illumination
3W LED , brightness adjustable

Item
Optional Accessories
Eyepiece
Eyepiece 10X/18
Extra Wide field eyepiece WF10x/ 22
Wide Field Eyepiece WF12.5x/ 14
Wide Field Eyepiece WF15x/ 16
Wide Field Eyepiece WF16x/ 12
Wide Field Eyepiece WF20x/ 12
Nosepiece Backward quintuple nosepiece
Objective

Semi Plan Achromatic Objective 4x /10X/40X/100X
Semi Plan Achromatic Objective 20x /60X
Infinite Plan Achromatic Objective 4x /10X/40X/100X
Infinite Plan Achromatic Objective 20x /60X
Nosepiece
Backward quintuple nosepiece
Polarization Set
Simple polarization set
Dark Field Condensor
Dark field condenser (Dry) N.A. 0.9
Dark field condenser (Oil) N.A. 1.25-1.36
Phase Contrast Kit Phase Contrast kit, dial type. Consisting of Phase Contrast Infinity Plan-achromatic Objectives 10X, 40X(S), 100X(S,Oil), Turret Annular Phase Contrast Condenser, Green Filter
Epi-Fluoresence attachment FL-LED, with B excitation filter (465-475 nm blue) and LED lamp
Illumination
Kohler illumination
