MBL.003094Infinity,Binocular/Trinocular Compound Microscope, 40X~1000X
  • /usr/575/images/Products/Y/57525151.jpg
  • /usr/575/Picture/Y/11667.jpg
  • /usr/575/Picture/Y/11668.jpg
  •

Advanced biological Microscope for educational, teaching, life science and clinical applications.

  • Extra Wide Field Eyepiece 10x/ 22
  • Infinite Plan Achromatic Objective
  • Backward quintuple nosepiece
Specification
MBL.003094-B
MBL.003094-T
Head
Seidentopf binocular head, inclined at 30°,360° Rotatable,interpupilary 47-75mm
Seidentopf trinocular head, inclined at 30°,interpupilary 47-75mm
Eyepiece
Extra Wide Field Eyepiece 10x/ 22
Objective
Infinite Plan Achromatic Objective 4x
Infinite Plan Achromatic Objective 10x
Infinite Plan Achromatic Objective 40x
Infinite Plan Achromatic Objective 100x(S)(Oil)
Nosepiece
Backward quintuple nosepiece
Focusing
Coaxial coarse & fine adjustment system, range 24mm, fine division 0.002mm
Stage
Double layer mechanical specimen stage. 216 x 150 mm Travel area 78 x 54 mm, Right hand stage handle
Condenser
Abbe condenser N.A.1.25 with Iris diaphram
Illumination
3W LED , brightness adjustable

Item
Optional Accessories
Eyepiece
Eyepiece 10X/18
Wide field eyepiece WF10x/ 20
Wide Field Eyepiece WF12.5x/ 14
Wide Field Eyepiece WF15x/ 16
Wide Field Eyepiece WF16x/ 12
Wide Field Eyepiece WF20x/ 12
Nosepiece Backward quadruple nosepiece
Objective

Semi Plan Achromatic Objective 4x /10X/40X/100X
Semi Plan Achromatic Objective 20x /60X
Infinite Plan Achromatic Objective 4x /10X/40X/100X
Infinite Plan Achromatic Objective 20x /60X
Nosepiece
Backward quintuple nosepiece
Polarization Set
Simple polarization set
Dark Field Condensor
Dark field condenser (Dry) N.A. 0.9
Dark field condenser (Oil) N.A. 1.25-1.36
Phase Contrast Kit Phase Contrast kit, dial type. Consisting of Phase Contrast Infinity Plan-achromatic Objectives 10X, 40X(S), 100X(S,Oil), Turret Annular Phase Contrast Condenser, Green Filter
Epi-Fluoresence attachment FL-LED, with B excitation filter (465-475 nm blue) and LED lamp
Illumination
Kohler illumination
