MBP.001001Polarizing Microscope

Equipped with strain-free plan achromatic objectives and wide field eyepiece
Coaxial coarse/fine focus system with tension adjustable and limit stopper, minimum division of fine focusing: 2μm
Take-down style polarizer, 360°rotatable, have 0,90,180,270 four scale, located down the aperture diaphragm
Impellent style analyzer, 360°rotatable, push in / out from optical path conveniently
Collector composed with field diaphragm and filter seat
Revolving round stage, 360°part scale and graduated in 1°increments, minimum resolution 6' when using vernier scale, center adjustable and with tightener
Illumination with 6V20W halogen lamp, adjustable brightness
Trinocular and digital & video camera can be chosen

Specification	MBP.001001-A	MBP.001001-B
Eyepiece	WF10X/18mm Wide Field
	Division eyepiece 10X (Ф18mm) 0.10mm/div
Head	Trinocular head,revolved (inclination of 30 °),100% image light for photography capable
Objectives	Strain-free Plan Achromatic PL 4X/0.10		Strain-free Infinity Plan Achromatic PL 4X/0.10
	Strain-free Plan Achromatic PL 10X/0.25		Strain-free Infinity Plan Achromatic PL 10X/0.25
	Strain-free Plan Achromatic PL 40X/0.65 (spring)		Strain-free Infinity Plan Achromatic PL 40X/0.65 (spring)
	Strain-free Plan Achromatic PL 100X/1.25(Spring,oil)		Strain-free Infinity Plan Achromatic PL 100X/1.25(Spring,oil)
Focus System	Coaxial coarse/fine system, with tension adjustable and up stop, minimum division of fine focusing 2um
Nosepiece	Quadruple, frontward ball bearing inner locating
Abbe Condenser	N.A. 1.25 rack & Pinion adjustable
Polarizer	360°rotatable, with four scale is 0°, 90°,180°,270°
Collector	For illumination with halogen lamp (with field diaphragm)
Stage	Rotatable stage, diameter \|μ150mm, 360° graduated (in 1° increasements), minimum retardation resolution 6' center adjustable and with tightener
Filter	Frosted filter
	Blue filter
Illumination Unit	With polarizer, 6V20w, halogen lamp, adjustable brightness

Item	Optional Accessories
Eyepiece	WF16x/11mm wide field
Eyepiece Tube	Binocular, inclination of 30°
Head	Strain-free plan achromatic PL 5x/0.12
	Strain-free plan achromatic PL 20x/0.40
	Strain-free plan achromatic PL 60x/0.85(Spring)
	Infinity strain-free plan achromatic PL 4X/0.10
	Infinity strain-free plan achromatic PL 20X/0.40
Nosepiece	Quintuple, frontward ball bearing inner locating
DC Adapter	Digital camera adapter CANON (A610,A620,A630,A640)
Filter	Green filter
Filter	Yellow filter
CCD Adapter	0.4X
	0.5X
	1X
	0.5X with dividing 0.1mm/Div
Photo Adapter	2.5X/4X Change over photograph adapter with 10X viewing eyepiece
	4X Focusing photograph adapter
	PK Adapter
	MD Adapter
