MBP.023077-T
|
MBP.023077-RT
|
|
Optical System
|
Infinity Color Corrected Optical System
|
|
Head
|
Compensation Binocular Head, 30° Inclined, 360° Rotatable, Interpupillary Distance 54-75mm, Diopter +/-5 Adjustable. |
| Eyepiece |
High Eye-point Wide Field Plan Eyepiece PL10x22mm |
|
Objective
|
LWD Infinity Plan Destressing Objectives 5x, 10x, 20x, 50x |
Infinity Plan Destressing Objectives 4x, 10x, 20x, 40x, 60x |
LWD Infinity Plan Destressing Objectives 5x, 10x, 20x, 50x |
|
|
Intermediate Tube With Removable Internal Bertrand Lens, Analyzer And Compensators. Bertrand Lens With Rotating Switch, Focusing Recyclable, Center Adjustable |
| Pluggable Analyzer, 360° Rotatable, 2° Increments, Precision 6', With Locking Device |
Compensator
Gyps 1λ（ Φ18mm, Optical Path Difference 551nm）;
Mical 1/4λ (Φ18mm, Optical Path Difference 147.3nm);
Quartz Wedge ( I-IV ) |
|
Focusing
|
Coaxial Focus System With Upper Limited And Tension Adjustment; Coarse Range 25mm; Fine Precision 0.002mm |
|
|
5 Holes Revolving Nosepiece, Inward, Center Adjustable |
|
|
Circular Metal Stage Dia.160mm, Graphite Coating, Anti-corrosive And Anti-friction, 360° Rotatable, 1° Increment, Precision 6′
|
|
Condenser
|
Swing-out Achromatic Condenser N.A 1.2, With 360° Rotatable Polarizer, Four Adjustable Scale: 0/90/180/270 |
|
Reflected Illumination
|
Reflected Light,
12V/50W Halogen Lamp House, Imported Bulb, Center presetting, Reflected Illuminator With LBD Filter And Pluggable Polarizer, Field Diaphragm And Aperture Diaphragm Adjustable
|
No Reflected Illumination |
Reflected Light,
12V/50W Halogen Lamp House, Imported Bulb, Center presetting, Reflected Illuminator With LBD Filter And Pluggable Polarizer, Field Diaphragm And Aperture Diaphragm Adjustable |
| Transmitted Illumination |
No Transmitted Illumination |
Transmitted Light,
12V/50W Halogen Lamp House, Imported Bulb, Center Presetting, With Iris Diaphragm
Filter For Transmitted Light Yellow, Neutral, IF550, LBD |
Transmitted Light,
12V/50W Halogen Lamp House, Imported Bulb, Center Presetting, With Iris Diaphragm
Filter For Transmitted Light Yellow, Neutral, IF550, LBD |
| Power |
Wide Range Voltage 100~240V AC 50/60Hz |
|
|
|
|
|
|
High Eye-point PL10x/22mm with Micrometer, Diopter Adjustable |
| High Eye-point PL15x/16mm |
| Working Stage |
Attachable Mechanical Moving Stage For Circular Stage, Moving Range: 30mm*40mm; High Precision Micrometer, 0.01mm Increment |
| CCD Adapter |
1x C-Mount, Focus Adjustable |
| 0.50x, For 1/2” C-Mount, Focus Adjustable |
| 0.67x, For 2/3” C-Mount, Focus Adjustable |
|
