MBP.038006Binocular/Trinocular Polarizing Microscope, 50X~500X, Reflected and Transmitetd Illumination
  • /usr/575/images/Products/Y/57520163.jpg
  •
  •
  •
  • Binocular/Trinocular Polarizing Microscope
  • Infinity independent achromatic optical system,50X~500X
  • Reflected and Transmitetd Illumination
Specification
MBP.038006-B
MBP.038006-T
Magnification 50x - 500x
Optical System UCIS infinity independent achromatic optical system
Head
Seidentopf binocular head 30° inclined, rotatable 360°,interpupillary distance 52-75mm

Seidentopf trinocular head 30° inclined, rotatable 360°,interpupillary distance 52-75mm
Eyepiece
Plan WF10x/20mm, high eyepoint up to 21mm,
Plan WF10x/20mm, polarizing reticule eyepiece
Objective
Infinity achromatic objectives 5X
Infinity achromatic objectives 10X
Infinity achromatic objectives 20X
Infinity achromatic objectives 50X
Nosepiece Quadruple, reversed type with positive click stops
Focusing Low positioned, coaxial coarse&fine focusing system with an adjustable tension control and upper limit stop, coarse 14mm/rot,fine 0.1mm/rot, minimum reading 1μm on left-side fine knob, moving range 20mm
Stage
Specimen holder
Rotating stage, size 142mm, pre-centered and 360° rotatable
Condenser
Swing-Out Condenser N.A.1.25
Polarization
The polarizer mounted under the condenser holder rotates 360° with click stops every 45°, scale 0°45°90°135°180°225°270°315°
The Intermediate tube has a analyzer with large rotation control dial for easy adjustment and accurate reading through rotations of 180°,division 1°,accuracy 6'. The built-in focusable and centerable Bertrand lens allows conoscopic observation. with compensator slot
Compensator Quartz wedge plate, I-IV class
λ Plate, first class red
1/4λ Plate
Filter Blue Φ38
Adapter   0.5x, C-Mount
Kohler Illumination With field diaphragm
Reflected Illumination 12V50W Power supply unit
12V100 Halogen lamp house
Reflected illuminator (single module)
Polarizer slider for reflected illuminator
Transmitetd Illumination 6V20W Halogen lamp, 110-240V wide voltage
6V20W halogen bulb (Osram)
250x/3.15A Φ5x20 fuse
Other Immersion Oil
Φ2mm Allen Screw Driver
Φ1.5mm Allen Screw Driver
Dust cover
Power cord

Item
Optional Accessories
Eyepiece
Plan eyepiece 16x/14mm
WF10X/22mm, high eyepoint up to 21mm
Objective Infinity plan achromatic objective 2x
Infinity plan achromatic objective 4x
Infinity plan achromatic objective 10x
Infinity plan achromatic objective 20x(S)
Infinity plan achromatic objective 40x(S)
Infinity plan achromatic objective 100x(S, Oil)
Strain-free infinity achromatic objective 60x(S)
Stage Attachable mechanical stage
Filter Φ38 Frosted Glass
Green
Yellow
Adapter 1.0x C-Mount
0.25x C-Mount
Illumination Electrical part for 6V30W halogen
Electrical part for 3W LED (with rechargeable battery)
Upgrade to electrical part for 3W LED
6V30W Halogen bulb
6V30W Halogen bulb (Osram)
3W LED bulb
