MBP.038007-T
|
| Magnification |
40x - 600x |
| Optical System |
UCIS infinity independent achromatic optical system |
|
|
Seidentopf binocular head 30° inclined, rotatable 360°,interpupillary distance 52-75mm
|
Seidentopf trinocular head 30° inclined, rotatable 360°,interpupillary distance 52-75mm
|
|
Eyepiece
|
Plan WF10x/20mm, high eyepoint up to 21mm, |
| Plan WF10x/20mm, polarizing reticule eyepiece |
|
|
Infinity strain-free achromatic objectives 4X |
| Infinity strain-free achromatic objectives 10X |
| Infinity strain-free achromatic objectives 40X |
| Infinity strain-free achromatic objectives 60X |
| Nosepiece |
Quadruple, reversed type with positive click stops |
| Focusing |
Low positioned, coaxial coarse&fine focusing system with an adjustable tension control and upper limit stop, coarse 14mm/rot,fine 0.1mm/rot, minimum reading 1μm on left-side fine knob, moving range 20mm |
|
|
Specimen holder |
| Rotating stage, size 142mm, pre-centered and 360° rotatable |
|
Condenser
|
Swing-Out Condenser N.A.1.25 |
|
Polarization
|
The polarizer mounted under the condenser holder rotates 360° with click stops every 45°, scale 0°45°90°135°180°225°270°315° |
| The Intermediate tube has a analyzer with large rotation control dial for easy adjustment and accurate reading through rotations of 180°,division 1°,accuracy 6'. The built-in focusable and centerable Bertrand lens allows conoscopic observation. with compensator slot |
| Compensator |
Quartz wedge plate, I-IV class |
| λ Plate, first class red |
| 1/4λ Plate |
| Filter |
Blue Φ38 |
| Adapter |
|
0.5x, C-Mount |
| Kohler Illumination |
with field diaphragm |
| Transmitetd Illumination |
6V20W Halogen lamp, 110-240V wide voltage |
| 6V20W halogen bulb (Osram) |
| 250x/3.15A Φ5x20 fuse |
| Other |
Immersion Oil |
| Φ2mm Allen Screw Driver |
| Φ1.5mm Allen Screw Driver |
| Dust cover |
| Power cord |
