MBC.038001Inverted Phase Contrast Microscope
  • /usr/575/images/Products/Y/57520412.jpg
  •
  •
  •
Specification
MBC.038001 Inverted Phase Contrast Microscope
Optical System UCIS infinity independent achromatic optical system
Head
Seidentopf trinocular head, 30° inclined, interpupilary distance 52-75mm, diopter adjustable; Frame 50:50
Eyepiece
Plan WF10x/20mm, high eyepoint up to 21mm,
Phase Contrast Attachment
Infinity L.W.D Plan Achromatic Phase-Contrast Positive Objective 4X
Infinity L.W.D Plan Achromatic Phase-Contrast Positive Objective 10x
Infinity L.W.D Plan Achromatic Phase-Contrast Positive Objective 20x
Infinity L.W.D Plan Achromatic Phase-Contrast Positive Objective 40x
Centering Telescope
4xphase contrast slid
40x phase contrast slide
Nosepiece
Quintuple Revolving Nosepiece Facing Inward
Focusing
Coaxial Coarse & Fine Focusing Knob
Stage
Fixed Stage + Attachable Mechanical Stage
Condenser
Phase Contrast Condensor
Illumination
6V 30W Osram Halogen Lamp
