MBI.003046Inverted Microscope
  • /usr/575/images/Products/Y/57517675.jpg
  • /usr/575/Picture/Y/10703.jpg
  •
  •
  • Inverted-design is available to observe liquid samples.
  • Small hand-held microscope, simple, good performance, high-definition.
  • Compact designing, owned power, easy to carry out to take wildlife observation and inspect protozoa in factory effluent and microbiology.
Specification
MBI.003046
Eyepiece
10x/ Φ18mm
Objective

Long Working Distance Achromatic 4x/0.08, W.D.16mm

Long Working Distance Achromatic 10x/0.25, W.D.3.6mm
Long Working Distance Achromatic 40x/0.6, W.D.0.6mm
Nosepiece
Triple
Stage
Plain Stage with Slide Clips
Range of Vertical Stroke
Up 1.6mm, down 1.0mm, total 2.6mm
Illumination
Brightfield, LED Illumination, AA Battery * 2

Item
Optional Accessories
Phase Contrast

Phase Contrast, LED Illumination, AA Battery *2

Phase Contrast 10x
Phase Contrast 20x
Phase Contrast 40x
Box
Portable Carring Box
