MBM.0400033-Person Multiple Viewing Microscope
  • /usr/575/images/Products/Y/57520662.jpg
  •
  •
  •

MBM.040003 3-Person Multiple Viewing Microscope

  • Three-Person Viewing Microscope is Suitable for discussion application in Clinic, Research and Teaching.
  • With infinity imaging system, 12V30W halogon lamp illumination system, it can provide sharp & clear image.
  • It is designed for 3 people to observe one specimen together at the same time.







Specification
MBM.040003 3-Person Multiple Viewing Microscope
Optical System Infinity Optical System
Head
 Compensation Free Binocular Head,Inclined at 30° Three Teaching Binocular Heads (55mm-75mm)
Eyepiece
Wide field eyepiece WF10x/22mm
Objective
Infinity Achromatic Objective 4x
Infinity Achromatic Objective 10x
Infinity Achromatic Objective 40x
Infinity Achromatic Objective 100x(S) oil
Nosepiece
Backward quadruple nosepiece
Focusing
 Coaxial Coarse & Fine Focusing Knobs,Scale:0.002mm
Stage
Double Layer Mechanical Stage, Size 180x150mm, Moving Range 75x50mm
Condenser
 Abbe Condenser N.A.=1.25, with Iris Diaphragm and Filter
Illumination
 Halogen Lamp 12V 30W, AC85-230V Continue Intensity Control,Kohler Illumination

Item
MBM.040003 Optional Accessories
Head Compensation Free Binocular Head, Interpupilary Distance 48-75mm
Compensation Free Trinocular Head, Interpupilary Distance 48-75mm
Eyepiece
 Wide Field Eyepiece WF16x
Wide Field Eyepiece WF20x
Objective

 Infinity Plan Achromatic Objective 4x
Infinity Plan Achromatic Objective 10x
Infinity Plan Achromatic Objective 20x
Infinity Plan Achromatic Objective 40x (s)
Infinity Plan Achromatic Objective 60x (s)
Infinity Plan Achromatic Objective 100x (s) oil
