MMU.003042Upright Metallurgical Microscope
  • /usr/575/images/Products/Y/57517752.jpg
  • /usr/575/Picture/Y/10771.jpg
  •
  •
  • Big Stage with Extra Large Moving Range 250×250mm.
  • It is widely used in IT Industry for Large Area Integrate Circuit, Wafer Observation and Inspection.
  • Excellent Optical Quality with Infinite Optical System and LWD High Magnification Objective(40X/ WD3.7mm).
  • Stage Speedy Movement by Hand to Get Observation Point Immediately.
  • Comfortable and Enjoyable Operation with Low and Pre Position Control Knob.

Specification
MMU.003042-34
MMU.003042-35
Head
Seidentopf Trinocular
Optical System
Infinity Optical System
Eyepiece

EW10x/22mm, Extra Wide Field

Objective
Infinity Plan Long Working Distance Achromatic Objective 4x/ 0.1/ ∞/-
Infinity Plan Long Working Distance Achromatic Objective 5x/0.12/ ∞/-
Infinity Plan Long Working Distance Achromatic Objective 10 x/0.25/ ∞/-
Infinity Plan Long Working Distance Achromatic Objective 10 x/0.25/ ∞/- (BF/DF)
Infinity Plan Long Working Distance Achromatic Objective 20x/ 0.4/ ∞/-
Infinity Plan Long Working Distance Achromatic Objective 20x/ 0.4/ ∞/-(BF/DF)
Infinity Plan Long Working Distance Achromatic Objective 40x/ 0.6/ ∞/0
Infinity Plan Long Working Distance Achromatic Objective 50x/0.75/ ∞/-

Infinity Plan Long Working Distance Achromatic Objective 100x/0.80/ ∞/0
Nosepiece
Quadruple
Quintuple
Focusing
Coaxial Coarse & Fine Adjustment, Range24mm
Stage
Large Working Stage Size 300*268mm, Extra Large Moving Range 250*250mm,
Fast Movement, Precision Adjustment
Filter
Green, Blue,Yellow, Ground glass
Illumination
6V/ 20W Halogen Lamp, Brightness Adjustable 24V/100W Halogen Lamp, Brightness Adjustable, With Dark Field

Item
Optional Accessories
Polarizing Simple Polarization Set, Analyzer and Polarizer
Adapter
C mount
