MMU.003043Motorize Auto-Focu Metallurgical Microscope
  • /usr/575/images/Products/Y/57517753.jpg
  • /usr/575/Picture/Y/10772.jpg
  •
  •
  • Laboratory metallurgical microscope, including bright field, dark field and polarization observation system.
  • Powerful transmitted and reflected system with Kohler illumination.
  • Ideal instrument for industry inspection and science research.
Specification
MMU.003043
Digital Camera
3.0M Pixels CMOS Camera
Resolution 2048*1536
Pixel Size 3.2um*3.2um
Maximum Frame Fate:
2048*1536 12f/s
1600*1200 20f/s
1280X1024 27f/s
1024X768 43f/s
Responsivity:1.0V/lux/s@550nm
Manual or Auto Exposure,Exposure Time Adjustable(1-500ms)
SNR: >43dB
Head
Seidentopf Trinocular Head Inclined at 30°, Interpupillary 48-75mm
Optical System
Infinity Optical System, Bright Field/Dark Field, DIC, Polarizing
Eyepiece

Extra Wide Field Eyepiece EW10x/22mm, Eyepiece Tube Dia.30mm

Objective
Infinity Plan Achromatic Objectives4x
Infinity Plan Achromatic Objectives 10x
Infinity Plan Achromatic Objectives 20x
Infinity Plan Achromatic Objectives 40x
Infinity Plan Achromatic Objectives100x
Nosepiece
Backward Quintuple Nosepiece
Motorized Control and /Manual Control To Change Objective
With 2 Adaptor Ring For BF/DF Objective Changeover
Focusing
Coaxial Coarse & Fine Adjustment, Auto-Focus Funtion
Motorized Control Built-in Dynamic Focusing System, Auto-Focus W/O Computer, Precision <1um
Stage
Maximum Sample Height 30mm
Leading Screw Stage, Size 234*176mm
Motorized Control, Movring Range X +/-38mm, Y +/-28mm, Precision <1um
Including:
--Specimen Holder
--Specimen Preparation Plate

Reflect Illumination
24V 100W Halogen Light, Brightness Adjustable
Kohler Illumination With Aspherical Condenser
Blue, Green, Yellow Filter, Gound Glass
Transmit Illumination
Swing-Out Condenser N.A.0.9/0.25
24V 100W Halogen Light With Aspherical Condenser
Blue Filter
Hardware System
USB2.0 Cable
USB Dog
Micrometer 0.01mm
Control Box of Motorized Auto-Focus Microscope
9-PIN Control Port Line
15-PIN Control Port Line
25-PIN Control Port Line
9-PIN Serial Port Line
3.5mm Auto Focus Signal Cable
Motorized Auto-Focus Microscope Control Software

Item
Optional Accessories
Objective
Infinity Plan Achromatic Objectives 40x/0.6/∞/0 (BF/DF),W.D.2.9mm
Polarizing
Polarizer & Analyzer, Intergrate Board For Polarizer & Analyzer |
For Reflect Illumination
Filter
Netural Filter ND25
Netural Filter ND6
Other
Specimen Presser
