MMU.003045Upright Metallurgical Microscope
  • /usr/575/images/Products/Y/57517755.jpg
  • /usr/575/Picture/Y/10773.jpg
  •
  •
  • Laboratory metallurgical microscope,including bright field,dark field,polarization and DIC observation system.
  • Powerful transmitted and reflected system with Kohler illumination.
  • Ideal instrument for industry inspection and science research.

Specification
MMU.003045-A
MMU.003045-B
Head
Seidentopf Trinocular Head Inclined at 30°, Interpupillary 48-75mm
Optical System
Infinity Optical System, Bright Field/Dark Field, DIC, Polarizing
Eyepiece

Extra Wide Field Eyepiece EW10x/22mm, Eyepiece Tube Dia.30mm

Objective
Infinity Plan Achromatic Objectives 5x/ 0.12/ ∞/ - (BF/DF),W.D.12mm
Infinity Plan Achromatic Objectives 10x/ 0.25/ ∞/ - (BF/DF),W.D.10mm
Infinity Plan Achromatic Objectives 20x/ 0.4/ ∞/0 (BF/DF),W.D.4.3mm
Infinity Plan Achromatic Objectives 50x/ 0.75/ ∞/0 (BF/DF),W.D.0.32mm
Infinity Plan Achromatic Objectives100x/0.80/∞/0 (BF/DF),W.D.2mm

Infinity Plan Achromatic Objectives 40x/0.65/∞/0.17,W.D.0.54mm

Infinity Plan Achromatic Objectives 100x/1.25/∞/0.17,W.D.0.13mm
Nosepiece
Backward Quintuple Nosepiece
Focusing
Coaxial Coarse & Fine Adjustment, Fine Focusing Precision <1um, With Safty Stop, With Tension Adjustment
Stage
Maximum Sample Height 50mm
Non-Porous Double Layer Mechanical Stage 186*138mm, Moving Range 74*50mm, Including:
Maximum Sample Height 30mm
Double Layer Mechanical Stage 186*138mm, Moving Range 74*50mm, Including:
--Specimen Preparation Plate
--Slide Glass
Reflect Illumination
24V 100W Halogen Light, Brightness Adjustable
Kohler Illumination With Aspherical Condenser
Polarizer & Analyzer, Intergrate Board For Polarizer & Analyzer
Blue, Green, Yellow Filter, Gound Glass
Transmit Illumination

Swing-Out Condenser N.A.0.9/0.25
24V 100W Halogen Light With Aspherical Condenser
Blue Filter

Item
Optional Accessories
Objective
Infinity Plan Achromatic Objectives 40x/0.6/∞/0 (BF/DF),W.D.2.9mm
DIC
20x, 100x DIC Slide
Polarizing
Polarizer & Analyzer, Intergrate Board For Polarizer & Analyzer |
For Reflect Illumination
Filter
Netural Filter ND25
Netural Filter ND6
Adapter
Photo Adapter, For Nikon or Canon SLR Camera
C-Mount 1.0x
C-Mount 0.5x
Other
Specimen Presser
