MMU.040028Binocular/Trinocular Upright Metallurgical, 40X~400X
  • /usr/575/images/Products/Y/57519721.jpg
  • /usr/575/Picture/Y/11602.jpg
  •
  •
  • This equipment can be used in observation, analysis and research of Metallurgy, Mineral, Crystal, Micro-electronics and it is the first choice for the factories, universities, research institutions and electronic industry.
  • It is adopted 2 kinds of illumination of reflection and transmission and also equipped with Epi-illumination Polarization devices. Under the reflected light, it can proceed Bright field and Polarizing observation.
  • It can also proceed Bright field observation under transmitted illumination. Stable, high-quality optical systems meet your requirement of high image quality, square-built body represents more rigid, T-shaped design gives you a more stable base. Humanized configuration design and convenient operation, Let you release form the pressure of heavy work. Let you devote experiment with entire energy.
Specification
MMU.040028-B
MMU.040028-T
Head
Compensation Free Binocular,30°inclined,55mm-75mm
Compensation Free Trinocular,30°inclined,55mm-75mm
Eyepiece
Wide field WF10X/22mm
Wide field WF10X/20mm with Crosshair 0.1mm
Objective
Infinity Metallurgical Objective 4X/0.1 W.D. 29.4mm
Infinity Metallurgical Objective 10X/0.25 W.D. 16mm
Infinity Metallurgical Objective 20X/0.4 W.D. 10.6mm
Infinity Metallurgical Objective 40X/0.6 W.D. 5.4mm
Nosepiece
Quadruple
Focusing
Coaxial coarse & fine adjustment system, range 28mm, fine division 0.002mm
Stage
Double Layer Mechanical, (Size180mmX150mm,Moving Range:75mmX50mm)
Condenser
Abbe condenser N.A.1.25 with Iris diaphram & filter
Flashboard Filter
Blue Filter
Green Filter
Neutral Filter
Checking Tool 0.01mm Micrometer
Polarizing Device Analyzer rotatable 360°, Polarize &Analyzer can be Mmoved in/out of the Optical Path
Light Source 12V/30W,AC 85V-230V
Illumination
EPI-Kohler Illumination with Apertrue Iris Diaphragm and Field Iiris Diaphragm
Transmission Light,Adjustble Brightness

Item
Optional Accessories
Eyepiece
Micrometer Eyepiece
Objective

Long Working Distance 5.1mm PL L50X/0.55B.D.
Long Working Distance 4mm PL L80X/0.75B.D.
Long Working Distance 3mm PL L100X/0.8B.D.
CCD Adapter
0.5X
0.57X
0.75X
Photo Adapter Photo Adapter
Planishing Tool Planishing Tool
CCD
CCD Camera,colour 1/3" High Resolution 520 TV lines
Software
Two-dimensional Measurement Software
Professional Metallurgical Iimage Analysis Software
