MMU.040029Binocular/Trinocular Upright Metallurgical, 40X~400X
  • /usr/575/images/Products/Y/57519726.jpg
  • /usr/575/Picture/Y/11603.jpg
  •
  •

This equipment can be used in observation, analysis and research of Metallurgy, Mineral, Crystal, Micro-electronics and it is the first choice for the factories, universities, research institutions and electronic industry.

Specification
MMU.040029-B
MMU.040029-T
Head
Compensation Free Binocular,30°inclined,55mm-75mm
Compensation Free Trinocular,30°inclined,55mm-75mm
  Wide field WF10X/22mm
Eyepiece
  Wide field WF10X/20mm with Crosshair 0.1mm
Objective
Infinity Metallurgical Objective 4X/0.1 W.D. 25mm
Infinity Metallurgical Objective 10X/0.25 W.D. 11mm
Infinity Metallurgical Objective 20X/0.4 W.D. 8mm
Infinity Metallurgical Objective 40X/0.6 W.D. 3.8mm
Nosepiece
Quadruple
Focusing
Coaxial Coarse and Fine Focusing with Rack and Pinion Mechanism; Fine Focusing Scale Value 0.002mm.
Stage
Double Layer Mechanical, Size:180mmX150mm,Moving Range:75mmX50mm)
Condenser
Abbe condenser N.A.1.25 with Iris diaphram & filter
Flashboard Filter
Blue Filter
Green Filter
Yellow Filter
Checking Tool 0.01mm Micrometer
Polarizing Device Analyzer rotatable 360°, Polarize &Analyzer can be Mmoved in/out of the Optical Path
Light Source 12V/30W,AC 85V-230V Halogen Bulb
Illumination EPI-Kohler Illumination with Apertrue Iris Diaphragm and Field Iiris Diaphragm
Transmission Light,Adjustble Brightness

Item
Optional Accessories
Objective
50X/0.75 W.D. 1.9mm
80X/0.9 W.D. 0.9mm
Photo Adapter Photo Adapter
