MMI.003036Inverted Metallurgical Microscope

Infinitive Optical System Providing Excellent Optical Functions. With the stable stand structure、advanced stage design and comfortable operation, it is widely used in institute and laboratory to observe and identify the structure of various metal and alloy.

Specification	MMI.003036
Head	Seidentopf Trinocular Head, 30° Inclined, Interpupillary 48~75mm, Diopter Adjustable
Optical System	Infinity Optical System
Eyepiece	Extra Wide Field Eyepiece EW10x/20mm, High Eyepoint
Objective	Infinity Plan Metallurgical Coverless Achromatic Objective 4x/0.1/∞/-, W.D.17.3mm
	Infinity Plan Metallurgical Coverless Achromatic Objective 10x/0.25/∞/-,W.D.10.2mm
	Infinity Plan Metallurgical Coverless Achromatic Objective 20x/0.4/∞/-,W.D.5.1mm
	Infinity Plan Metallurgical Coverless Achromatic Objective 40x/0.65/∞/-, W.D.0.52mm
Nosepiece	Quintuple Nosepiece
Focusing	Coaxial Coarse & Fine Adjustment, Coarse Stroke 37.7mm Per Rotation, Fine Stroke 0.2mm Per Rotation
Stage	Plain Stage 160*250mm With Slide Clips
Polarizing	Polarizing Attachment
Filter	Green, Blue, Yellow, Ground Glass, Dia.45mm
Illumination	External Kohler Illumination, Halogen Lamp 6V30W, Brightness Adjustable

Item	Optional Accessories
Objective	Infinity Plan Metallurgical Coverless Achromatic Objective 5x/0.12/∞/-, W.D.15.4mm
	Infinity Plan Metallurgical Coverless Achromatic Objective 50x/0.75/∞/-, W.D.0.32mm
	Infinity Plan Metallurgical Coverless Achromatic Objective 80x/0.9/∞/-, W.D.0.20mm
	Infinity Plan Metallurgical Coverless Achromatic Objective 100x/0.9/∞/0, W.D.0.7mm
Wokring Stage	Attachable Mechanical Stage, X-Y Coaxial Control, Moving Range 120*78mm
	Auxiliary Stage 70*180mm
	Terasaki Holder
	Petri Dish Holder Dia.38mm
	Slide Glass Holder Dia.54mm
	Slide Glass Holder Dia.90mm
Adapter	Photo Adapter
	C-Mount 1.0x
	C-Mount 0.5x
