MMI.038009Inverted Metallurgical, 100X~400X, UCIS infinity optical system
  • /usr/575/images/Products/Y/57520218.jpg
  •
  •
  •
  • UCIS Infinity Independent Achromatic Optical System
  • It is widely used in cytology, parasites, oncology, immunology, genetic engineering, industrial microbiology, botany and other fields.
Specification
MMI.038009
Optical System UCIS infinity independent achromatic optical system
Head
Seidentopf binocular head, 45° inclined, interpupillary distance 52-75mm, ±5 diopter adjustment
Eyepiece
WF10x/20mm, plan, high eyepoint up to 21mm
Objective
Infinity LWD plan achromatic objective 10x/0.25 WD9.67
Infinity LWD plan achromatic objective 20x/0.40 WD7.97
Infinity LWD plan achromatic objective 40x/0.60 WD3.76
Infinity LWD plan phase contrast objective 20x/0.40 WD7.97
Nosepiece Quintuple, reversed type with positive click stops
Focusing Low positioned, coaxial coarse&fine focusing system with adjustable tension control and upper limit stop, minimum reading 1μm, moving range 12mm
Condenser Abbe condenserN.A. 0.30 with iris diaphragm, with phase contrast slider & filter (φ34) blue,green & yellow, long work distance 72mm
Stage
Right hand controls, low position, mechanical stage, size 240x260mm, moving range 135x85mm.
Drop specimen holder(φ118)
Specimen holder (76x26, φ54)
Centering Attachment Centering telescope
Phase Contrast Phase contrast slider (for 10x/20x/40x phase contrast and brightfield observation)
Light Source 6V30W Halogen lamp house
6V30W Power supply unit
6V30W halogen bulb (Osram)
250V/3.15A Φ5X20 Fuse
Power supply 110-240V 50/60Hz
Phase contrast slider Phase contrast slider for 10x
Phase contrast slider for 20x
Phase contrast slider for 40x
Adapter
0.5x, C-Mount
Frame One-piece construction from arm to base
Other

Allen screw driver 2.5mm
Allen screw driver 2mm
Power cord
Dust cover

Item
Optional Accessories
Eyepiece
WF10x/20mm, plan, high eyepoint up to 21mm, diopter adjustable
WF10x/22mm plan eyepiece, high eyepoint
WF16x/13mm, plan
Head Seidentopf binocular head,45° inclined, interpupillary distance 48-75mm, diopter adjustable
Objective Infinity plan achromatic objective 4x
Infinity LWD plan achromatic objective 60x
Infinity LWD plan phase-contrast objective 10x (positive)
Infinity LWD plan phase-contrast objective 40x (positive)
Infinity LWD Plan Phase-Contrast Objective 10x (Negative)
Infinity LWD Plan Phase-Contrast Objective 20x (Negative)
Infinity LWD Plan Phase-Contrast Objective 40x (Negative)
Bulb 6V30W Halogen bulb
Specimen Holder 125x85
Stage Mechanical Stage, Size 350x208mm,Moving Range 50x50mm
Adapter 0.25x C-Mount (suitable for 1/3" CCD)
Digital Camera Adapter, (Need To Know Camera Model Number)
Fluorescence Attachment 100W Mercury lamp house
100W Power supply unit
100W Mercury bulb
100W Mercury bulb (Osram)
Epi-fluorescent illumination,multi-functional semi-reflector
UV (Superior Grade)
V (Superior Grade)
B (Superior Grade)
G (Superior Grade)
UV (Common Grade)
V (Common Grade)
B (Common Grade)
G (Common Grade)
