Head

Seidentopf Trinocular Head, 30° Inclined, Interpupillary 48~75mm, Diopter Adjustable

Optical System

Infinity Optical System

Eyepiece

Infinity Plan Achromatic Objective 4x

Infinity Plan Achromatic Objective 10x

Infinity Plan Achromatic Objective 40x

Infinity Plan Achromatic Objective 100x

Backward Quintuple Nosepiece

Focusing

Coaxial Coarse & Fine Adjustment, Focusing Range 24mm, Fine Division 0.001mm, Coarse Stroke 37.7mm

Double Layer Mechanical Stage, 185*142mm, Moving Range 55*75mm

Condenser

Swing Condenser N.A.0.95/0.25

LED Fluorescent System

LED Reflected Flourescent System
1) 3W LED Fluorescent Light 465~475nm
2) Fluorescent Free Oil
3) Blue Excitation Filter, BP460~490, DM505, BA515

Illumination

External Kohler Illumination, Asperical Collector, Halogen Lamp 6V30W, Brightness Adjustable

Fluorescent System



Infinity Plan Fluorescent Objective 4x/0.13/0.17, W.D.16.3

Infinity Plan Fluorescent Objective 10x/0.3/0.17, W.D.12.4

Infinity Plan Fluorescent Objective 20x/0.5/0.17,W.D.1.5

Infinity Plan Fluorescent Objective 40x/0.75/0.17,W.D.0.35

Infinity Plan Fluorescent Objective 100x/1.3/0.17,W.D.0.13

--3W LED Fluorescent Light 525-530m
--Green Excitation Filter, BP510~550, DM570, BA590

Adapter

Photo Adapter
