MFU.023080Binocular/Trinocular Upright Fluorescent, 100X~1000X, LED
  • /usr/575/images/Products/Y/57518579.jpg
  • /usr/575/Picture/Y/11489.jpg
  • /usr/575/Picture/Y/11490.jpg
  •
  • Infinity color corrected optical system with high quality micro-technique pres-ents superexcellent micro-image at any observation.
  • Wide-field high eye-point eyepieces and plan achromatic objectives make the effect of fluorescence observation more perfect.
  • Outstanding appearance design and ergonomics structure design, long time use without feeling tired.
  • With the design of security lock and safe limits, it is much more secure, stab-le. and can be kept for long.
  • Various microscopic examinations can be fulfilled, such as bright-field, dark-field, phase contrast, fluorescence, simple polarizing and so on.
  • LED Illumination
Specification
MFU.023080
Head
Trinocular, 30° Inclined, Interpupillary Distance 50-75mm
Eyepiece
PL10x/20mm, Wide Field, High Eye Point, Diopter Adjustable +/-5 Degree
Objective Infinity Plan Achromatic 10x/0.25, 20x/0.50, 40x/0.65, 100x/1.25
Nosepiece
Backward Quadruple
Focusing
Low Position Coaxial Coarse & Fine Focusing Knob, with Safty Limitation and Tension Adjustment Ring. Coarse Range 25mm, Fine Precision 0.002mm
Stage
Double Layer Mechanical Stage 150*140mm, Moving Range 76*50mm, Precision 0.1mm
Condenser
Kohler N.A. 1.25, with Socket for Phase Contrast and Dark Field Slides, Center Fixed
Filter Blue, Dia.45
Fluorescent LED Fluorescent Moudle, with Brightness Adjust Knob, Bright Field Fluorescent Switch Knob, LED Wave Length 470, Band B1
Light Source 3W LED, Intensity Adjustable, Center Fixed
Power 90~240V Wide Range Power Supply

Item
Optional Accessories
Head Binocular, 30° Inclined, Interpupillary Distance 50-75mm
Eyepiece
PL10x/22mm, Wide Field, High Eye Point, Diopter Adjustable +/-5 Degree
Fluorescent

LED Fluorescent Moudle, with Brightness Adjust Knob, Bright Field Fluorescent Switch Knob,LED Wave Length 560, Band G1
LED Fluorescent Moudle, with Brightness Adjust Knob, Bright Field Fluorescent Switch Knob,LED Wave Length 365, Band UV2
LED Fluorescent Moudle, with Brightness Adjust Knob, Bright Field Fluorescent Switch Knob,LED Wave Length 455, Band B4
Nosepiece
Backward Quintuple
Adapter



C-Mount 1.0x, Focus Adjustable
C-Mount 0.5x, Focus Adjustable , for 1/2 CCD
C-Mount 0.35x, Focus Adjustable, for 1/3 CCD
Photo Adapter with PK or MD mount, with 3.2x Photo Eyepiece
Professional Photo C Mount, with Photo Eyepiece
Battery Box Specially Designed For LED Fluorescence Microscope
Output DC6V, Large Capacity 5000mA, Rechargable
Size 26*16*11cm
