MFU.023081Binocular/Trinocular Upright Fluorescent, 100X~1000X, Halogen
  • /usr/575/images/Products/Y/57518581.jpg
  • /usr/575/Picture/Y/11492.jpg
  •
  •
  • Infinity color corrected optical system with high quality micro-technique pres-ents superexcellent micro-image at any observation.
  • Wide-field high eye-point eyepieces and plan achromatic objectives make the effect of fluorescence observation more perfect.
  • Outstanding appearance design and ergonomics structure design, long time use without feeling tired.
  • With the design of security lock and safe limits, it is much more secure, stab-le. and can be kept for long.
  • Various microscopic examinations can be fulfilled, such as bright-field, dark-field, phase contrast, fluorescence, simple polarizing and so on.

Specification
MFU.023081
Head
Binocular, 30° Inclined, Interpupillary Distance 50-75mm
Eyepiece
PL10x/20mm, Wide Field, High Eye Point, Diopter Adjustable +/-5 Degree
Objective Infinity Plan Achromatic 10x/0.25, 20x/0.50, 40x/0.65, 100x/1.25
Nosepiece
Backward Quadruple
Focusing
Low Position Coaxial Coarse & Fine Focusing Knob, with Safty Limitation and Tension Adjustment Ring. Coarse Range 25mm, Fine Precision 0.002mm
Stage
Double Layer Mechanical Stage 150*140mm, Moving Range 76*50mm, Precision 0.1mm
Condenser
Kohler N.A. 1.25, with Socket for Phase Contrast and Dark Field Slides, Center Fixed
Filter Blue, Dia.45
Fluorescent
  • Reflected Fluorescent Illuminator, 100W Lamp House, Power Unit
  • Fluorescent Filter B,G
Light Source 6V30W Halogen , Intensity Adjustable, Center Fixed, including 6V30W Bulbs 2 pcs
Power 100~240V Wide Range Power Supply

Item
Optional Accessories
Head Trinocular, 30° Inclined, Interpupillary Distance 50-75mm
Eyepiece
PL10x/22mm, Wide Field, High Eye Point, Diopter Adjustable +/-5 Degree
Fluorescent
Fluorescent Filter UV
Nosepiece
Backward Quintuple
Adapter



C-Mount 1.0x, Focus Adjustable
C-Mount 0.5x, Focus Adjustable , for 1/2 CCD
C-Mount 0.35x, Focus Adjustable, for 1/3 CCD
Photo Adapter with PK or MD mount, with 3.2x Photo Eyepiece
Professional Photo C Mount, with Photo Eyepiece
