Specification
|
MLB.003084
|
|
LCD Screen
|
8 Inch TFT Touching Screen,1280X720
|
|
Image Sensor
|
3.0 Mega Pixels CMOS Chip
|
|
Digital Interface
|
USB2.0、Mini USB, HDMI , Support Wifi and Bluetooth ,Support SD Card
|
|
Head
|
Compensation Free Binocular Head, Inclined at 30°, Interpupillary 52-75mm
|
|
Eyepiece
|
Wide Field Eyepiece WF10x/18mm |
|
Objective
|
Infinite Semi-Plan Achromatic Objective 4x
|
|
Infinite Semi-Plan Achromatic Objective 10x,
|
|
|
Infinite Semi-Plan Achromatic Objective 40x
|
|
|
Infinite Semi-Plan Achromatic Objective 100x
|
|
|
Nosepiece
|
Quadruple Nosepiece
|
|
Focusing
|
Coaxial Coarse & Fine Adjustment, Moving Range 20mm
|
|
Stage
|
Double Layer Mechanical Stage, Size 140x140mm, Moving Range 75x50mm
|
|
Condenser
|
Sliding-in Centerable Condenser N.A.1.25
|
|
Illumination
|
LED collector, bright and white light
|
|
Software
|
TouchScope
|
|
Operating Syetem
|
Android 4.2.2
|
