LCD Biological Microscope, 9.7'' LCD, 5M, 40~1000X_IHPVISION:Microscope,Digital Vision

MLB.001009LCD Biological Microscope, 9.7'' LCD, 5M, 40~1000X

This microscopes is equipped with infinity plan achromatic objectives and wide field eyepieces.

9.7’’ LCD Screen,resolution 1024*768
5.0M CMOS Image Sensor built-in
It have beautiful sculpt and provide clear image, wide field, convenience operation.
It can be used for biology medicine agriculture and industry area widely.
It is the ideal instrument in medical treatment, teaching demonstration and scientific research.

9.7" LCD Pad with Andriod System of MLB.001009
Specification of LCD PAD	LCD Screen	9.7" HD Diagonal IPS LCD Resolution 1024*768 Backlight Screen, Five Point Touch Screen, Hardware Power Switch
	CPU	1.6GHz Four Core ARM Mali-400 MP GPU Support OpenGL ES 1.1/2.0 And OpenVG 1.1 Support Full HD 1080p Support Android 4.2 System
	RAM	2GB, Support DDR3, DDR2, LPDDR2
	Data Storage	SD Card Slot, Support Max 32GB C10 High Speed SD Card
	Data Interface	HDMI, Mini USB2.0, USB 2.0
	Operation System	Android 4.2 System, Multi Language
	Power	Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor, Power Mode : Normal, Sleep, Power Off
	WIFI	Support
	Bluetooth	Support
	Software	YX Camera Installed, --Can Adjust Real Time Image --Can Measure Length, Area, Angle, Count --Can Take Picture, Record Video YX Image Installed --Grey, Contrast, Brightness Adjust --Binary Image For Granular Count Both Software Chinese/English Version, With Instruction Manual Installed
	Product Size	Pad 17.522.52.0cm
	Package Size	Packing Box 102429cm, 1 pc/Box
Specification of Digital Camera	Senser	1/2.5" CMOS, Color, Aptina MT9P001
	Resolution	5.0M Pixels, Maximum Photo Resolution 2592*1944
	Pixel Size	2.2um*2.2 um
	Effective Image Size	5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
	Frame Rate	1280720/15 Fps, 640480/30Fps
	Dynamic Range	66.5dB
	SNR	40.5dB Max
	ADC	12 Bit, On Chip
	Shutter Type	ERS, Auto
	White Balance	Auto
	Connect	Standard C-Mount Interface

Specification of Main Body

Specification	Main Body of MLB.001009
Eyepiece	WF10X(Φ22mm)
Head	Trinocular,inclination of 30°
Infinity Plan Achromatic Objective	PL 4X/0.10 (Work distance)：21 mm
	PL 10X/0.25 (Work distance)：5.0 mm
	PL 40X/0.65 (Spring) (Work distance)：0.66 mm
	PL 100X/1.25 (Spring, oil) (Work distance)： 0.36mm
Focusl System	Coaxial coarse/fine focus system, Minimum division of fine focusing: 2um With tensional adjustable and up stop
Nosepiece	Quadruple (backward ball bearing inner locating)
Stage	Double layer mechanical, size 180x150mm, moving range 75x50mm
Condenser	Abbe N.A.1.25 Rack & pinion adjustment
Filter	Blue filter and Ground glass
Collector	For LED lamp
Light source	LED, High Brightness, Light Adjustable
