LCD Biological Microscope, 9.7'' LCD, 5M CMOS, 40~1000X

MLB.001012LCD Biological Microscope, 9.7'' LCD, 5M CMOS, 40~1000X

It is very suitable for usage in medical test,teaching and microobservation in hospitals and schools.

9.7" LCD Pad with Andriod System of MLB.001012
Specification of LCD PAD	LCD Screen	9.7" HD Diagonal IPS LCD Resolution 1024*768 Backlight Screen, Five Point Touch Screen, Hardware Power Switch
	CPU	1.6GHz Four Core ARM Mali-400 MP GPU Support OpenGL ES 1.1/2.0 And OpenVG 1.1 Support Full HD 1080p Support Android 4.2 System
	RAM	2GB, Support DDR3, DDR2, LPDDR2
	Data Storage	SD Card Slot, Support Max 32GB C10 High Speed SD Card
	Data Interface	HDMI, Mini USB2.0, USB 2.0
	Operation System	Android 4.2 System, Multi Language
	Power	Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor, Power Mode : Normal, Sleep, Power Off
	WIFI	Support
	Bluetooth	Support
	Software	YX Camera Installed, --Can Adjust Real Time Image --Can Measure Length, Area, Angle, Count --Can Take Picture, Record Video YX Image Installed --Grey, Contrast, Brightness Adjust --Binary Image For Granular Count Both Software Chinese/English Version, With Instruction Manual Installed
	Product Size	Pad 17.522.52.0cm
	Package Size	Packing Box 102429cm, 1 pc/Box
Specification of Digital Camera	Senser	1/2.5" CMOS, Color, Aptina MT9P001
	Resolution	5.0M Pixels, Maximum Photo Resolution 2592*1944
	Pixel Size	2.2um*2.2 um
	Effective Image Size	5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
	Frame Rate	1280720/15 Fps, 640480/30Fps
	Dynamic Range	66.5dB
	SNR	40.5dB Max
	ADC	12 Bit, On Chip
	Shutter Type	ERS, Auto
	White Balance	Auto
	Connect	Standard C-Mount Interface

Specification of Main Body

Specification	Main Body of MLB.001012
Head	Binocular head inclination 30°
Eyepiece	WF10X(Φ18mm)
Objective	Semi-plan 4X/0.10
	Semi-plan 10X/0.25
	Semi-plan 40X/0.65(Spring)
	Semi-plan 100X/1.25(Spring, oil)
Focusl System	Coaxial coarse/fine focus system, Minimum division of fine focusing: 2um With tensional adjustable and up stop
Nosepiece	Quadruple Backward ball bearing inner locating
Stage	Double layer mechanical, size 160x140mm, moving range 75x50mm
Condenser	Abbe N.A.1.25 Rack & pinion adjustment
Filter	Blue filter
Filter	Frosted filter
Collector	For halogen lamp
Light source	6V 20W halogen lamp with brightness control
