MLB.057001 3.5" Student LCD Microscope
|
| LCD Monitor |
3.5” digital TFT display |
| LCD Rotation |
180° – 90° left / 90° right |
| Digital Camera |
5 MP 1/2.5 ” CMOS; 10x Magnification in lieu of an Eyepiece |
| Memory |
1GB Memory SD Card |
| Objectives |
Achromatic, glass type 4x, 10x 20x, 40x |
| Nosepiece |
Quadruple nosepiece |
| Focuser |
Coarse/Fine |
| Stage |
Mechanical Stage 3.5” x 3.5” (88 mm x 88 mm) |
| Illuminators |
Up and Down LED Light |
| Condenser |
N.A. 0.65 |
| Filter Wheel |
Red/Green/Blue/1 mm hole/3 mm hole/6 mm hole (default) |
| AC Adapter |
Input Universal 100 to 240 Volt 50/60HZ |
| Output |
USB 2.0 Cable |
| Batteries |
User supplied 4AA — approx. 3 hour usage |
| Weight/Dimensions |
67 oz/1.9 Kg 7.0” (178 mm) x 5.5” (140 mm) x 13.0” (330 mm) |
