MLS.0630027 Inch LCD Zoom Microscope with LED Ring Light
  • /usr/575/images/Products/Y/57520502.jpg
  • /usr/575/Picture/Y/11643.jpg
  •
  •
  • With 7 inch Screen
  • A good helper for reparing electrical equipment like mobilephone, watch or PCB board.
  • AV output, can be connected with TV
Specification
MLS.063002 7 Inch LCD Zoom Microscope with LED Ring Light
LCD 7" LCD Screen
Total Magnification 7-45x
Zoom Ratio
1:6.5
Eyepiece WF10X/20mm
Head
Trinocular Head, 45 ° inclined,interpupillary 55-75mm
Objective 0.7X-4.5X
Field of View φ5mm-φ30mm
Diopter
Binocular diopter adjustment range ±5
Stage vertical arm stage,200mm×255mm
Working Distance 30mm-160mm
Light Source LED,brightness adjustable.
