MMP.003040Portable Metallurgical Microscope
  • /usr/575/images/Products/Y/57517750.jpg
  •
  •
  •
  • Available to precisely Adjust magnification.
  • Eyepiece10× with reticule and diopter adjustment .
  • Various of Reticules for Eyepiece to Meet Different Requirements.

Specification
MMP.003040-20
MMP.003040-40
MMP.003040-50
MMP.003040-100
Total Magnification
20X
40X
50X
100X
Power of Objective
2X
4X
5X
10X
Mechanical Tube Length
160mm
WF Eyepiece
30mm
Diameter of Viewing field in Eyepiece
Φ18mm
10x Reticule Eyepiece
0.1 Micrometer
Filter
Green, Blue,Yellow, Ground glass
Diameter of Base
Φ63mm
Height of Microscope
210mm
Mass of Microscope
0.65kg
Illumination
Pen light, 2pcs AAA battery
