MDB.003002Biological Digital Microscope, 1.3M CMOS, 40X~1000X
  • /usr/575/images/Products/Y/57517734.jpg
  • /usr/575/Picture/Y/10755.jpg
  •
  •
  • Integrated digital microscope, 1.3M resolution 1280×1024
  • USB2.0 output, plug and unplug freely
  • Support WINDOWS 2000/XP/VISTA system,Equipped with powerful applied software
  • Economic features, widely used in academic demonstration and health system
Specification
MDB.003002
Viewing Head
Sliding Binocular Head, Inclined at 45° inclined, Interpupilary 55-75mm
  • Digital Camera 1.3M Pixlels, 1280x1024
  • USB 2.0 Output
  • Operation System: Windows 2000/XP/Vista
  • Software : ScopeImage Plus
  • Range of Viewing Field >75%
Eyepiece
WF10X/ 18
Objective
Achromatic Objective 4x
Achromatic Objective 10x
Achromatic Objective 40x
Achromatic Objective 100x
Nosepiece
Forward Quadruple Nosepiece
Stage
Double Layers Mechanical Stage 140X140mm/75X50mm
Condenser
Abbe N.A.=1.20 with Iris Diaphragm & Filter
Focusing
Coaxial Coarse & Fine Focus Adjustment, Moving Range:28mm, Fine Division 2um
Light Source
Halogen Lamp 6V/20W , with brightness adjustable, 110V/220V




Item
Optional Accessories
Eyepiece
P16x/11
