MDB.001062Biological Digital Microscope, 1.3M CMOS, USB2.0, 4X
  • /usr/575/images/Products/Y/57517806.jpg
  •
  •
  •

MDB.001062 Nail Fold Microcirculation Checking Microscope, also named as " Microcirculate Checkup Microscope" is a new type of optical & electronic instrument, equipped with achromatic objective, new type LED illumination, high definition color sensor.

It is mainly applied to nail fold microcirculation checking, no any hurt and side-effect in the checking process. It is the ideal instrument for disease forepart diagnosis, health care etc.

Specification
MDB.001062-3KV
MDB.001062-1MU
Color Sensor
Video Output
1/3"CMOS, 380 TV lines
Automatic white balance
USB Output
1/3"CMOS, 1.3M
USB2.0
Objective
Achromatic 4x/0.10
Power Adapter
Input 220V/110V, output 9V
Movable Stage
Mechanism moving stage, size 130x118mm, moving range 64x28mm
Video Cable
Standard Video cable, length:1.8m
LED Illumination
High quality LED, brightness and illuminate's angle adjustable

Item
Optional Accessories
Objective
Plan achromatic 5X/0.12
