MDB.001056Biological Digital Microscope, 1.3M CMOS, USB2.0, 40X~1000X

MDB.001056 Digital Biological Microscopes, newly designed in 2008, is equipped with 1.3M CMOS digital head, achromatic objectives and wide field eyepieces. It can provide clear image, wide field, convenience operation, can be used for medicine agriculture area widely. They are the ideal instruments in medical treatment, teaching demonstration.

Digital head built-in 1.3M CMOS USB output
With wide field eyepieces and achromatic objectives, the field of view is widely and clear
Coaxial coarse/fine focus system. Minimum division of fine focusing: 4μm
High brightness white LED lamp transmission illumination

Specification	MSM.001047-1K3	MSM.001047-3K3	MSM.001047-1M4
Digital Head	CMOS 1/2", resolution 100K, USB 1.1, Auto White Balance Monocular,360° rotatable (Inclination of 45°)	CMOS 1/2", resolution 300K, USB 1.1, Auto White Balance Monocular,360° rotatable (Inclination of 45°)	CMOS 1/2", resolution 1.3M, USB 2.0, Auto White Balance Monocular,360° rotatable (Inclination of 45°)
Eyepiece	WF10X plan eyepiece, focal length 25mm, field Φ18mm
Eyepiece	Huygens 15X(Φ11mm)
Objective Parfocalization distance 35mm	Achromatic 4X/0.10	Achromatic 4X/0.10	Achromatic 4X/0.10
	Achromatic 10X/0.25	Achromatic 10X/0.25	Achromatic 10X/0.25
	Achromatic 40X/0.65(Spring)	Achromatic 40X/0.65(Spring)	Achromatic 40X/0.65(Spring)
			Achromatic 100X/1.25(Spring, oil)
Nosepiece	Triple nosepiece (Frontward ball bearing outer locating)	Triple nosepiece (Frontward ball bearing outer locating)	Quadruple nosepiece (Frontward ball bearing outer locating)
Focus System	Coaxial coarse/fine focus system. Minimum division of fine focusing: 4μm.	Coaxial coarse/fine focus system. Minimum division of fine focusing: 4μm.	Coaxial coarse/fine focus system. Minimum division of fine focusing: 4μm.
Stage	Fixed(Size:120mmX120mm, With five holes fixed iris diaphragm)	Fixed(Size:120mmX120mm, With five holes fixed iris diaphragm)	Double layer mechanical, size 135x125mm, moving range 75x35mm
Collector	For LED lamp
Light source	High brightness white LED lamp
Software	With image analysis software in English version

Item	Optional Accessories
Eyepiece	Wide field WF16X(Φ11mm)
Eyepiece	Point 10X(Φ18mm)
Stage	Fixed(Size:120mmX120mm, With single lens and iris diaphragm)
Stage	Fixed(Size:120mmX120mm, with slide moving holder and Abbe condenser)
Filter	Blue filter
	Green filter
	Yellow filter
	Frosted filter
Collector	For Fluorescent and Halogen lamp
Collector	For Incandescent lamp
Light source	High brightness white LED lamp With adapter
	High brightness white LED lamp With adapter and charge batteries
	Halogen lamp 12V 20W
	Fluorescent lamp 110V/220V, 5W Can be choose
	Incandescent lamp,220V/110V, 20WCan be choose
