Specification
|
MDB.023049
|
| Digital Camera |
3.0M Buitl-in Digital Camera, USB 2.0, Automatic Exposure, Automatic White Balance, Display 90% Image From Field of View. Line By Line Scan.
|
|
Head
|
Binocular, 30° Inclined, 360° Rotatable, Interpupillary Range 50~75mm
|
|
Eyepiece
|
PL10x/18mm, Wide Field, High Eyepoint |
|
Objective
|
Achromatic Objective 4x/0.10
|
|
Achromatic Objective 10x/0.25
|
|
|
Achromatic Objective 40xs/0.65
|
|
|
Achromatic Objective 100xs/1.25 Oil
|
|
|
Nosepiece
|
Reversed Quadruple
|
|
Focusing
|
Coaxial Coarse & Fine Focusing, Low Position Design, Coarse Focusing Range 28mm, Fine Focusing Precision 0.002mm, With Tension Adjustment and Up Limit
|
|
Stage
|
Double Layer Mechanical Stage, 140*132mm, Moving Range 76*50mm, Precision 0.1mm, Double Slide Holer, Low Position Coaxial Regulating Handles
|
|
Condenser
|
Abbe N.A.1.25 Condenser, With Iris Diaphragm, With Filter Holder
|
|
Light Source
|
Variable voltage 90V～240V, 3W LED lamp with intensity control
|
|
Power
|
90~240V Wide Range Voltage
|
