Specification
|
MDB.023050-3M
|
MDB.023050-5M
|
| Optical System | Finite color corrected optical system | |
|
Digital Camera
|
3.0M CMOS Digital Camera
|
5.0M CMOS Digital Camera
|
| Output Interface | USB 2.0 Output | |
|
Head
|
Binocular Head, 30° Inclined, Diopter Adjustable +/-5°, Interpupillary Distance 50~75mm
|
|
| Eyepiece |
WF10x/18mm
|
|
| Objective |
Plan 4x,10x,40x(S),100x(O,S)
|
|
| Nosepiece |
Backward, Quarduple Nosepiece
|
|
| Focusing | Low Position Designed, Coaxial Coarse & Fine Focusing, Coarse Focusing Range 25mm, Fine Focusing Scale 0.002mm, With Tension Adjustment, With Upper Safty Stop | |
| Stage | Double Layer Mechanical Stage, Size 132*140mm, Moving Range 50*76mm, Precision 0.1mm | |
| Condenser | Abbe N.A.1.25, With Iris Diaphragm, Fixed But Centeradjustable | |
| Light Source | 3W LED High Brightness | |
| Power | Wide Voltage AC100~240V Input, DC 6V1A Output | |
|
Operating System
|
Microsoft Windows XP / Vista / win7 (32 & 64 bit) / win8 (32 & 64 bit)
|
|
