MDB.0030325.0M Digital Compound Microscope
  • /usr/575/images/Products/Y/57520262.jpg
  •
  •
  •
  • 5.0M Digital Compound Microscope
  • USB2.0 Output
  • Comfortable operation with updated and ergonomic design





Specification
MDB.003032 5.0M Digital Compound Microscope
Digital Camera
Pixel
5.0M
Max Resolution
2592x1944
Pixel Size
2.2um x 2.2um
CCD Sensor
1/2.5"
Sensor Size (mm)
5.70x4.28
Sensitivity(@550nm)
0.53v/lux-sec
DynamicRange
66.5dB
SN Ratio
40.5dB
Frame Rate
5fps;18fps;60fps
Binning
1x1;2x2;4x4
Exposure
0.21~2000ms
Output
USB 2.0,support No driver required
A/D Conveter
12-bit, 8-Bit R.G.B to PC
White balance
Auto/Manual
Scan Mode
Progressive

Main Body
Head
Siedentopf trinocular head, inclined at 30°, interpupilary Distance 55-75mm
Eyepiece
Wide field eyepiece WF10x/ 18
Objective
Achromatic objective 4x
Achromatic Objective 10x
Achromatic Objective 40x
Achromatic Objective 100x
Nosepiece
Backward quadruple nosepiece
Focusing
Coaxial coarse & fine knob, moving range 24mm, fine division 0.004mm
Stage
Double layers mechanical stage132x142mm/ 75x40mm
Condenser
Abbe condenser N.A.1.25 with Iris diaphram & filter
Illumination
LED 3W, brightness adjustable

Item
Optional Accessories
Eyepiece
P16x/11
Illumination
Halogen lamp 6V/ 20W, brightness adjustable
