MSZ.003071Zoom Stereo Microscope, 8X~80X
  • /usr/575/images/Products/Y/57517763.jpg
  • /usr/575/Picture/Y/10781.jpg
  •
  •

Fluorescent stereo microscope realizes fluorescence observation of living cell,widely used in biology,industrial inspection,criminal justice etc.It is an essential tool of fluorescence inspection for security printing and ideal instruments for mineral research.

Specification
MSZ.003071-06
MSZ.003071-08
MSZ.003071-10
Head
Tilting Head 0°-35° Viewing Angle Adjustable for User
Optical System Parallel Optical System, Module Design to Add Function Easily
Eyepiece

Extra Wide Field Eyepiece EWF10x/22mm
Zoom Objective

0.8×-5×

0.8×-6.4×

0.8×-8×
Zoom Ratio

1: 6

1: 8

1: 10
Auxiliary Lens Plan Achromatic Lens 1.0x
Working Distance 78mm

Focusing

Focusing Range 105mm

 Focusing Range 105mm

Coaxial Coarse & Fine Focusing Unit,Moving Range 105mm
Photo Tube Photo Tube, Beamsplitter 1 Port
Fluorescent --Fluorescent Filter System Including
GFP-B(EX480-500,DM505,BA510-560)
GFP-L(EX460-500,DM505,BA510)
--100W Ultra Hi-Voltage Spherical Mercury Lamp
--Power Supplier NFP-1, Digital Display
Illumination

Transmission or Reflection LED Illumination, Brightness Adjustable

Item
Optional Accessories
Eyepiece WF15x/16mm
WF20x/12mm
WF30x
Auxiliary Lens Plan Apochromatic Lens 0.5x

Plan Achromatic Lens 1.0x
Plan Achromatic Lens 2.0x
Achromatic Lens 0.3x

Achromatic Lens 0.5x
Working Stage Temperature Control Stage
Movable Working Stage
Dark Field Dark Field Attachment For Stereo Microscope
Fluorescent GFP-B(EX430-450,DM455,BA465-495)
GFP-B(EX430-450,DM455,BA465-495)
G(EX515-550,DM5750,BA590)
RFP-B(EX525-555,DM570,BA585)
Illumination Coaxial Illumination Set:
--Cold Light Power Supplier
--Dual Light Guide
--Coaxial Episcopic Illuminator
--Iris Diaphragm
Iris Diaphragm
Adapter Photo Adapter, 2.0x, For Nikon or Canon DIgital SLR Camera
0.5x C-Mount
1.0x C-Mount
