| Total Magnification |
7x ~ 63x
|
|
|
Trinocular head,45° Inclined, Interpupillary Distance 55 ~ 75mm, ±5 Diopter Adjustment，Parfocal Distance 10mm
|
|
Eyepiece
|
Extra Wide Field, Plan WF10x/22mm, High Eyepoint, Eyepiece Tube Φ 30mm |
|
|
Zoom Range 0.7x ~ 6.3x, Zoom Ratio 1:9
|
| Field Range |
Φ33.8 ~ Φ3.49 |
| Working Distance |
110cm
|
| Focusing Sytem |
Track Stand, Coaxial Coarse & Fine Focusing Knob
|
|
|
Size 310 x 280mm, With Specimen Clips
|
|
Vertically Effective Movement Range
|
220mm |
|
Power Supply
|
Input 85V~265V 50/60Hz, Output 12V |
| Illumination |
High Brightness, Reflected 3W LED & Transmitted 5W LED, Brightness Adjustable |
|
|
|
|
|
|
WF15x/15mm
|
|
WF20x/12mm
|
|
WF25x/9mm
|
|
WF10x/22mm, Dividing Eyepiece
|
|
Auxiliary Lens
|
1.5x, Total Magnification 10.5x ~ 94.5x
|
|
2x, Total Magnification 14x ~ 126x
|
| Fluorescent Illuminator |
Epi - LED Fluorescent Illuminator (B,G),3W LED Power Supply |
|
Epi - LED Fluorescent Illuminator (B,G,UV,V),3W LED Power Supply
|
| Ring Fluorescent Illuminator |
| Illumination (Halogen Lamp) |
High Brightness, Reflected & Transmitted , Brightness Adjustable, Both 30W Halogen Lamp
|
| Camera Adaptor
|
0.4x, C-Mount
|
|
0.5x, C-Mount
|
| 1x, C-Mount |
| 0.5x, C-Mount With Dividing |
Digtial Camera CANON (EF) / NIKON (F)
|
|
