Stereo Digital Microscope, 3M/5M CMOS, USB2.0, 6.6X~50X

MDB.004002Stereo Digital Microscope, 3M/5M CMOS, USB2.0, 6.6X~50X

Dustproof, moisture-proof, against disassemble, built-in digital chip, integrated design.
Light distribution 20:80,eyepiece observation synchronized with the imaging from digital camera.
Built in 3MP/5MP digital camera,1/2'' CMOS colorful sequential scanning.
USB2.0 connection, without external power supply.
Available for WINDOWS 2000 /XP/ 7 /Vista system.

Specification	MDS.004002-3M	MDS.004002-5M
Eyepiece	WF10x/23mm, high eyepoint, diopter adjustable (with eyecup)
Viewing Head & Zoom Body	Built-in 3MP digital camera system,1/2’’CMOS color sequential scanning , inclined 45°, Interpupillary Distance 54mm-76mm, Zoom Ratio 1:7.6	Built-in 5MP digital camera system,1/2’’CMOS color sequential scanning , inclined 45°, Interpupillary Distance 54mm-76mm, Zoom Ratio 1:7.6
Objective	Built-in 1x
Zoom range	0.66x-5x
Magnification	6.6x-50x
Stage	Double Layers Mechanical Stage 115×125mm/70×20mm
Working Distance	110mm
Focusing	Focus unit
Stand	Arm stand
Stage	Black & white plate
	Glass plate
Interface	USB2.0
System	Available for WINDOWS 2000 /XP/ 7 /Vista
Light Distribution	2:8, eyepiece observation synchronized with digital imaging without switching
Illumination	Reflecting lamp 3W LED (optional :12V/15W halogen)
	Transmitting lamp 3W LED (optional :12V/15W halogen)

Item	Optional Accessories
Eyepiece	WF20x/13mm high eyepoint,diopter adjustable (with eyecup)
Eyepiece	WF25x/11mm high eyepoint,diopter adjustable (with eyecup)
Auxiliary Objective	0.5x W.D.189mm
	0.75x W.D. 122mm
	2x W.D. 36mm
