MDB.004003Stereo Digital Stereo Microscope, 3M/5M CMOS, USB2.0, 7X~46X
  • /usr/575/images/Products/Y/57517680.jpg
  • /usr/575/Picture/Y/10711.jpg
  •
  •
  • Dustproof、dampproof、prevent disassembling built-in chip integrative design.
  • Light distribution 20:80, eyepiece observation synchronized with computer imaging without switching.
  • Built-in 3MP/5MP Digital camera system,1/2’’CMOS color sequential scanning .
  • USB2.0 connection, without external power supply.
  • OPTPro image analysis software , Available for WINDOWS 2000/XP/Vista system.
Specification
MDS.004003-3M
MDS.004003-5M
Eyepiece
WF10x/22mm, high eyepoint, diopter adjustable (with eyecup)
Viewing Head & Zoom Body Built-in 3MP digital camera system,1/2’’CMOS color sequential scanning , inclined 45°, Interpupillary Distance 54mm-76mm, Zoom Ratio 1:6.6

Built-in 5MP digital camera system,1/2’’CMOS color sequential scanning , inclined 45°, Interpupillary Distance 54mm-76mm, Zoom Ratio 1:6.6

Objective

Built-in 1x

Zoom range
0.7x-4.6x
Magnification
7x-46x
Stage
Double Layers Mechanical Stage 115×125mm/70×20mm
Working Distance

110mm

Focusing
Focus unit
Stand

Arm stand

Stage
Black & white plate
Glass plate
Interface
USB2.0
System
Available for WINDOWS 2000 /XP/ 7 /Vista
Light Distribution
2:8, eyepiece observation synchronized with digital imaging without switching
Illumination

Reflecting lamp 3W LED (optional :12V/15W halogen)

Transmitting lamp 3W LED (optional :12V/15W halogen)



Item
Optional Accessories
Eyepiece

WF15x/17mm

WF20x/13mm
Auxiliary Objective
0.5x W.D.189mm
0.75x W.D. 122mm
2x W.D. 36mm
