Specification
|
MAD.002007-91 Digital Eyepiece for Microscope
|
|
MAD.002007-92 Digital Eyepiece for Telescope
|
|
Pixel
|
800K
|
1.4M
|
2.0M
|
3.2M
|
|
Max Resolution
|
|
|
|
|
|
Pixel Size
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Sensitivity(@550nm)
|
|
|
|
|
|
DynamicRange
|
|
|
SN Ratio
|
|
|
|
|
|
|
|
|
Binning
|
1x1
|
|
Exposure
|
Normal: 0.16~62.00ms
Long Exposure: 62.98ms~4mins
|
Normal: 0.22~119.37ms
Long Exposure: 119.37ms~4mins
|
Normal: 0.17~100.00ms
Long Exposure: 100.00ms~4mins
|
Normal: 0.18~77.81ms @2048 x 1536, 0.18~23.10ms @640 x 480.
Long Exposure: 77.81ms~4mins
|
|
Output
|
|
|
A/D Conveter
|
12-bit Parallel, 8-bit R.G.B to PC
|
|
Scan Mode
|
|
|
Spectral Range
|
400-650nm (with IR-Filter) 380-1000nm (w/o IR-Filter)
|
|
Exposure
|
Electronic Rolling Snap(ERS),ROI Auto & Manual,
|
|
White balance
|
One Push ROI White Balance/ Manual Temp-Tint Adjustment
|
|
Driver Interfaces
|
|
|
Operating System
|
Microsoft Windows XP / Vista / 7 (32 & 64 bit)
CPU: Intel Pentium 4, 2.6G or above
RAM: 512 MB
HDD: 10 GB
USB: USB2.0 interface
|
|
Operating Temp.
|
|
|
Operating Humidity
|
|
|
Power Supply
|
|
|
Package Box
|
|
|
Color Rendering Technique
|
Ultra FineTM Color Engine
|
|
Capture Mode
|
|
|
Remarks
|
Actual frame rates on your computer depend on the hardware and operating system used
|
|
MAD.002007 Software Features
|
|
Main Functions
|
Viewing live images; Streaming & recording live videos; Capturing & saving still images; Making measurements
|
|
Processing
|
-Edits images in a similar manner to PhotoShop
-Captures images, records videos and saves in JPG, TIF, GIF, PSD, WMF, and BMP formats
-Add layers, watermarks, mosaics, tiles
-Adjust color balance, exposure, saturation, contrast, orientation
-Change resolution, histogram, granulation, diffusion
-Transform images via edge detection, digital image warping
|
|
Measurement
|
Measures length and angle; rectangular, elliptical and irregular areas; single, parallel and perpendicular lines
|
|
Notation
|
Adds notes, measurements, text, arrows, labels, and etc. using customizable text with different sizes and colors
|
|
Calibration
|
Makes measurements in microns, millimeters, centimeters, inches, feet, and etc. at all magnification settings with desired tolerances
|
|
MAD.002007 Driver Characteristics
|
|
White Balance
|
ROI auto white balance/temp-tint manual white balance
|
|
Black Level Calibration
|
Adaptive black level calibration
|
|
Stuck or Hot Pixel
|
Hardware remove technique
|
|
USB Controller Compatibility
|
Automatic detection of adaptation
|
|
Interfaces Supported
|
DirectShow/TWAIN
|
|
Operating System
|
Microsoft Windows XP / Vista / 7 (32 & 64 bit)
|
| |
