MAC.003075Digital Camera, CMOS, 1.3M, USB2.0
- High sensitivity, low noise, excellent color correction
- USB2.0 live video transfer
- Compatible with Windows 2000/ XP/ Vista/Win7
- Easy and fast software installation
- User-friendly and sophisticated image processing applications
- Premium optical lens adapter
|
|
|
|
Image Sensor
|
1.3MP 1/2 inch CMOS Image Sensor(4:3)
|
|
|
1280×1024
|
|
Pixel size
|
5.2μm×5.2μm
|
|
|
15fps@1280x1024
|
|
Shutter type
|
Electronic rolling shutter (ERS)
|
|
Sensitivity
|
>1.0 V/lux-sec (550nm)
|
|
Dynamic range
|
61dB
|
|
SNR
|
43dB
|
|
Image Output
|
USB2.0, Directshow and Twain
|
|
Operating System
|
Windows 2000/ XP/ Vista/Win7/Win 8/Mac
|
|
Operating temperature
|
0°C ~ 60°C
|
|
Packaging Contents
|
Software
|
ScopeImage 9.0
|
|
Cable
|
USB2.0 cable
|
|
Adapters
|
Eyepiece tube adapters Ф23.2/ Ф30 OR Ф23.2/ Ф30.5
|
|
| |
|
|
|
|
|
ScopeImage Advanced |
|
Stage Micrometer
|
Calibration slide 0.01mm and 0.1mm
|
|
