MAC.031002Digital Camera,CMOS,5M,USB3.0
  • /usr/575/images/Products/Y/57518104.jpg
  •
  •
  •
  • USB 3.0 Output
  • Standard C/CS Mount for Microscope, Telescope or Other Optical Device
  • Support Windows System 32/64 Bits Version, Support Ubuntu10 System
Specification
MAC.031002
Senser
1/2.5" CMOS, Color
Pixels
5.0M
Max Resolution
2592*1944
Pixel Size
2.2*2.2μm
Max FPS
14fps (2592*1944)
Output Digi
8 Bits
Exposure
Progressive Exposure
SNR
38.1dB
Dynamic Range
70.1dB
Sensititive (550nm)
1.4V/lux-sec
I/O Control
2 Way Input, 2 Way Output
Data Interface
USB 3.0
Power Supply
USB Power Supply
Max Power
2.5W
Lens Mount
Standard C/CS Mount, Adjustable
System

Windows All System 32/64 Bits Version
Support Ubuntu10 System

Software Control Function
  • Image Resolution Control
  • RGB Gain
  • Overall Gain
  • Exposure Time
  • Contrast
  • Gamma Table
  • Image Reverse
  • Color Mode
  • Saturation
Other Funtion
  • Manual / Auto White Balance, Exposure
  • White Balance, Exposure Control in Any Area
  • Bright Spot Remove
  • Balanced Brightness
  • User-defined Hardware Encryption
  • Support DSHOW, TWAIN Interface
Product Size
51*52*60mm
