Specification
|
MAC.033001-3M
|
MAC.033001-5M
|
MAC.033001-10M
|
|
Effective Pixels
|
3.0MP
|
5.0MP
|
10.0MP
|
| Resolution(HXV) |
2048X1536
|
2592X1944
|
3664X2748
|
| Sensor |
Micron MT9T001
|
Micron MT9P031
|
Micron MT9J001
|
|
Sensor Size
|
1/2''
|
1/2.5''
|
1/2.3''
|
| Pixel Size |
3.2X3.2um
|
2.2X2.2um
|
1.67X1.67um
|
| Frame Rate |
|
|
|
| Integration Time(S) |
0.001-0.5
|
0.001-0.8
|
0.001-1
|
| Dynamic Range |
54dB
|
60dB
|
56dB
|
| Color/monochrome | Color | ||
| Scan Mode | Progressive | ||
| Shutter | Rolling shutter | ||
| Color Depth | 24bit | ||
| A/D | 8bit | ||
| Exposure Control | Manual/Auto | ||
| White Balance | Manual/Auto | ||
| Operating Temperature | 0-60 | ||
| Operating Humidity | 45%-85% | ||
| Storage Temperature | -20-70 | ||
| Operating System | Windows/ Linux /Mac | ||
| Optical Port | C-Mount | ||
| Data Interface | USB2.0 | ||
